Building in map free as gift in our unit In order to ensure that the product can fit in your car well, Could you please answer us a few questions before we prepare the order for you: 1 Could you please take the dash board picture of your car and send to us to check? 2 Could you tell us your car specific model and year? 3 Does your car come with factory amplifier and factory navigation? 1.Main configuration： Items Description Remark Master CPU RockChip PX5 28nm chip processing Octa 64 bit Cortex-A53 CPU Maximum 1.5GHz Memory DDR3 2GB flash eMMC 32GB MCU The 32 bit Mainstream ARM controller、STM32F030RCT6 Bluetooth/WIFI/3G Onboard System integration Radio module ST6686M（Standard） Main power chip RK819-2 GPS RF receipt chip Onboard System integration DVD chip Copile860XCF DVD decoder SPHE8288 Audio process Rohm BD37533 3section EQ Amplifier TCB001 Start/stop amplifier 4X45W Display interface and resolution TTL/LVDS two interface、Maximum support 1080P high signal display TP Capacitive touch screen Operating system Android 8.0 2.Main functions and Parameter support： Functions Description Remark Display board Screen 5-13inch Resolution 800*480,1024*600,1024*768 , Maximum 1080P Display interface TTL LVDS Color depth 16bit 24bit Radio AM/FM Support RDS Support DAB digital Radio Support Support external DAB mould、USB interface、but don’t support Auto switch (Not test yet) Bluetooth Bluetooth phone Support External MIC Build in MIC as default、support external MIC Bluetooth phonebook Support A2DP Support Protocol Bluetooth 4.0,HFP/HSP,A2DP,AVRCP,Phonebook download Navigation GPS(USA) Support GLONASS(Russia) Support Beidou(China) Support TV Analog TV build in Not applicable External tv box Alternative: Analog or digital (optional) Digital TV build in Not applicable External TV box Support Audio player Media type APE，FLAC，MP3，WMA，WAV，OGG,etc. Video player Media type AVI,RM,RMVB,WMV,ASF,FLV,DAT,MPG,MP4,VOB,3GP等,硬解码RMVB 1080P,etc. Image browser Image type JPEG、BMP、GIFimage display，image preview,etc. IPOD USB interface Not applicable DVR USB Interface Support USB DVR Mobile Phonelink Android system Support (Android 8.0) Easyconnect Iphone IOS system Support (IOS11) Voice control Nuance Not applicable ADAS Need to add front camera Support front camera via AUX connecting Optional TPMS Models test approved Support Optional OBD OBD II Support Optional Audio process Standard Support Volume、Bass、Treble、Balance、Fader、Loudness、EQ USB Suppoprt 3 way USB,4-64GB 2 way USB2.0，1way USB3.0，support Audio, image, video play 2 USB as default, while some models with 3 way come with front USB slot, some models with 1 way as model construction SD card Support one SD card,4-64GB SD3.0 Support SDHC, Audio, image, video play Some models no have SD slot as model construction WIFI Wifi Support protocol 802.11 b/g/n 3G Network mode 2G(GSM/GPRS),3G(WCDMA/HSDPA 21.1Mbit/s) AUTO brightness control ILL detection Support Reverse Reverse when power on Reverse speedy before device start-up Normal reverse Switch in 1 second Reverse track Support Reverse camera power supply Support Current must be less than 200 mA Rearview output CVBS Support External DVD Not applicable 3.Basic performance 1 Operating temperature Range：-20℃–70℃ The chip(-40℃–85℃) 2 Operating humidity 5% to 95% under state of Non condensation 3 Operating voltage 9V～16V Dormant current ≤ 9mA Standby current ≤ 3mA 4 Reverse when turn on ACC 1.5 seconds 5 Normal reverse 1 second System quick start-up time 3 seconds(from dormant state to normal work) 6 System cold start-up time Within 30 seconds(From dept standby to normal operation) All information above for reference, any change will keep updating, if there any question for the information,feel free to contact us. 4.External interface instruction： Interface function Description Remark Power cable 16PIN WINCA standard USB 3 way standard interface 2 way 60PIN and 4PIN(USB adapter/original USB) as standard, 6pin USB adapter as optional As models construction Radio antenna Standard Compatible with WINCA device External MIC 3.5 head phone Compatible with WINCA device Analog TV antenna One way Compatible with WINCA device Digital TV antenna Two way Can support double antenna Multi-functions PIN External DVD interface Yes，But don’t support external DVD function External TV box interface Yes Reverse video input interface Yes DVR interface Yes 3 way USB interface Yes CAN interface One way UART steering wheel 2 way ADC detection RCA interface One AUX IN One Reverse camera CVBS input One Stereo audio output One subwoofer output 1 CVBS screen output Remark： ※All 9.0models just support external TV box ※All 9.0models can’t support external DVD box ※Some models can’t build in MIC, but can support external MIC cable as the construction. ※Some models don’t support SD card as models construction, can copy the MAP data to EMMC or USB to read.
